• Frame - Molybdenum steel with double cradle split above the exhaust port

• Wheelbase - 1482 mm

• Max length - 2175 mm

• Max width - 830 mm

• Max height - 1270 mm

• Seat height - 930 mm

• Ground clearance - 320 mm

• Footrest height - 407 mm

• Dry weight - 103,5 kg (front 50,8 kg; rear 52,7 kg)

• Fuel tank capacity - 9,5 l

• Reserve - 2,3 l

• Cooling system capacity - 1,3 l

• Front suspension - Hydraulic USD fork with ø 48 mm shaft

• Rear suspension - Monoshock with progressive compound lever

• Shock absorber stroke - 132 mm

• Front wheel travel - 295 mm

• Rear wheel travel - 290 mm

• front brake - Wave disc ø260 mm and double-piston floating caliper

• Rear brake - Wave disc ø240 mm and single-piston floating caliper

• Front rim - 21 x 1,6 – 36 holes

• Rear rim - 18 x 2,15 – 36 holes

• Front tyre - 90/90 – 21

• Rear tyre - 140/80 -18
